BOLT DIA. |
HEIGHT (A) |
SWL TENSION |
COIL DIA. (E) |
COIL LENGTH (B) |
WIRE DIA. (F) |
LENGTH (D) |
MIN. EDGE DISTANCE |
WEIGHT |
BOX QTY |
|
|
(LBS.) |
|
|
|
|
|
(LBS.) |
|
1/2" |
1-3/4" |
950 |
1-1/4" |
1-1/8" |
.225" |
4-1/2" |
4" |
0.26 |
100 |
3/4" |
2-1/4" |
2,000 |
1-5/8" |
1-5/8" |
.306" |
5" |
5" |
0.56 |
100 |
3/4" |
3-1/2" |
3,400 |
2" |
2" |
.306" |
6" |
6" |
0.67 |
80 |
1" |
2-5/16" |
2,000 |
2" |
2" |
.306" |
6" |
5" |
0.79 |
50 |
1" |
4-1/2" |
4,750 |
2" |
2" |
.306" |
6" |
8" |
0.97 |
50 |
