BOLT DIA. | INSERT LENGTH (L) | COIL DIA. (A) | COIL LENGTH (B) | WIRE DIA. (D) | LOOP DIA. (W) | SWL TENSION | WEIGHT | BOX QTY |
(LBS.) | (LBS.) | |||||||
1" | 12" | 2-1/16" | 2-1/16" | .375" | 5-1/2" | 9,500 | 2.4 | 20 |
1" | 12" | 2-1/4" | 2-1/16" | .440" | 5-3/4" | 13,500 | 3.1 | 20 |
1-1/4" | 12" | 2-5/16" | 2-1/16" | .375" | 5-3/4" | 9,500 | 2.5 | 20 |
1-1/4" | 12" | 2-1/2" | 2-1/16" | .440" | 5-3/4" | 13,500 | 3.2 | 20 |
1-1/2" | 12" | 2-9/16" | 2-3/8" | .375" | 5-3/4" | 9,500 | 2.7 | 20 |
1-1/2" | 12" | 2-3/4" | 2-3/8" | .440" | 5-3/4" | 13,500 | 3.4 | 20 |
